XCubeNXT

XN8116

Flexibility for Diverse Workloads Demanding More Performance

CPU

Intel® Xeon® 4-core Processor​​

RAM

32 GB DDR4 ECC DIMM (up to 512 GB)

High Availability​

Fully Redundant Modular Design​

Build-in High Speed​

Benefits of 10 GbE Network​

Flexibility for Diverse Workloads Demanding More Performance

The XCubeNXT 8116 (3.5” 3U 16-bay) is the newest generation of XCubeNXT that is flexible for diverse workloads which demand more performance. Highly available and secure with multiple protocol and cross QSAN platform support, it is designed to be ideal for applications in mission-critical data centers, high-performance computing, virtualization, or media environments. Plus, backed by a 5-year limited warranty for proven enterprise-grade reliability.

Enterprise Data Management System QSM Logo

QSM Data Management System​

QSM data management system provides high scalability, easy management, and data integrity to build a perfect unified storage system. Deploy your storage within 5 minutes via quick installation. Plan ahead with cloud backup and secure your data with multi-level security.​​​

Why QSAN XCubeNXT Arrays?

Modern Simplicity

Simplify storage management with the intuitive and powerful QSM storage manager interface.

Dependable Data Experience

99.999% high availability design with no single point of failure, cache-to-flash to protect cache data in power outage.

Flexible Expansion

Dual controller with built-in 4-port 10 GbE and maximum 26 host ports allows direct connection to multiple hosts without switches.

Enclosure Status LED Enclosure Access LED Enclosure Power Button / LED Disk Drive Status LED Disk Drive Power LED USB Port UID (Unique Identifier) Button / LED Power Supply Unit Master / Slave LED (only for dual controllers) Controller Status LED Dirty Cache LED UID (Unique Identifier) LED 12 Gb/s SAS Wide Port 10 GbE LAN Port 1 GbE LAN Port Host Card Slot 1 (host card is an optional part) Service Port Console Port USB Port Host Card Slot 2 (host card is an optional part) Reset to Factory Default Button Buzzer Mute Button

System Specifications

Architecture XN8116D: Dual-active controller
XN8116S: Single-upgradeable controller
Storage OS QSM Specification Details
CPU
Processor Intel® Xeon® 4-core (8-core processor models are also available)
Memory
Memory Module Pre-installed 16 GB DDR4 ECC DIMM (per controller)
Total Memory Slots 4 (per controller)
Memory Expandable up to 256 GB (per controller)
Storage
Drive Bays

3.5" Slot x 16
Maximum Drive Bays with Expansion Unit 496
Compatible Drive Type

3.5" & 2.5" SAS, NL-SAS, SED HDD

3.5" & 2.5" SATA(*) HDD

2.5" SAS, SATA(*), SED SSD
Drive Interface

SAS 12 Gb/s, SATA 6 Gb/s(*)
Maximum Internal Raw Capacity 352 TB (calculate 22 TB HDD)
Maximum Raw Capacity with Expansion Units 10,912 TB (calculate 22 TB HDD)
Hot Swappable Drive
Notes

(*) SATA drives only work with single controller systems
Connectivity Port
PCIe Expansion (Gen 3x8 Slot) x 2
{0} GbE RJ45 LAN Port 1 (onboard per controller)
{0} GbE SFP+ LAN Port 4 (onboard per controller) / 4 (option)
{0} GbE RJ45 LAN Port 2(option) / 4 (option)
{0} GbE SFP28 LAN Port 2(option) / 4 (option)
{0} Gb SFP+ Fibre Channel* 2(option) / 4 (option)
{0} Gb SFP28 Fibre Channel* 2 (option)
Expansion and External Port
12 Gb/s SAS Wide Port 2 (onboard per controller)
USB Port 1 (front) / 2 (rear)
Others Console Port x 1, Service Port (UPS) x 1
Software Specification
Storage OS QSM 4
RAID Type 0 / 1 / 3 / 5 / 6 / 10 / 30 / 50 / 60 / 5EE / 6EE / 50EE / 60EE
Storage Efficiency Thin Provisioning / Deduplication* (option) / Compression* (option)
Software Acceleration SSD Cache / Auto Tiering / RDMA
Data Protection Snapshot / Asynchronous / Synchronous* (option)
Backup Services Rsync* / S3 backup* / Cloud sync* / XMirror* / Microsoft 365 email backup
Security SSL / SED / WORM / RBAC / Windows ACL
Support Protocols CIFS / NFS / FTP* / AFP* / iSCSI / FCP
Management Web UI / Window AD / LDAP / RESTful API* / S.E.S. / LCM
Notes * The feature is still under developing, please contact QSAN for accurate release date.
Appearance
Dimension (H x W x D) (mm) 130.4 x 438 x 515
Net Weight (kg) 21.7
Gross Weight (kg) 24
Others
Memory Protection Cache-to-Flash (Supercapacitor Module + Flash Module) (option)
System Fan 4 pcs
Power Supply Unit 850 W x 2 (80 PLUS Platinum)
Power Consumption 534 W
Environment Temperature
Operating Temperature 0°C to 40°C
Storage Temperature -10°C to 50°C
Operating Relative Humidity 20% to 80% non-condensing
Non-operating Relative Humidity 10% to 90%
Certification
Certifications CE / FCC / BSMI
Warranty
Standard Warranty System: 5 years
Supercapacitor Module: 1 year
